Raymarine ST40 Speed Display E22037

  • Image 1
1.50 KGS
Free Shipping

Product Description

Brand New

Raymarine ST40 Speed Display

ST40 Display for Transom Mount or ThruHull Speed systems


Raymarine ST40 Speed Display for use in Seatalk or ST40 systems as a repeater or installed as a master display combined with a suitable Speed Transducer.


Raymarine ST40 Speed Display could be installed as a master display combined with Transom mount or ThruHull transducers (sold seperately) or as a repeater for displaying speed at multiple locations. The ST40 Speed Display is SeaTalk compatible and integrates with Raymarine autopilots, Raymarine Chartplotters (multifunction displays) and other navigation equipment.

The ST40 Speed Display has big high contrast LCD display with extra-large 7 segment 28mm sized digits for excellent visibilityin all lighting conditions and 3 levels of display-backlighting for night use. Speed display units can be chosen between knots (KTS), miles per hour, (MPH) or kilometers per hour (KPH) for Current speed, Maximum and Average speed. Log and trip information is presented in nautical miles (NM), statute miles (M) or kilometers (KM). Water temperature is displayed in Celsius or Fahrenheit degrees.

Mounting hardware's (bezels, surface and bracket) color of ST40 Speed Display could be chosenbetween 3 finishes (Carbon fiber, Silver, Grey).

The ST40 Speed Display includes a SeaTalk cable, mounting hardware, suncover and instructions.


Raymarine ST40 Speed Display Features:

  • SeaTalk compatible for networking to other instruments, multifunction displays and autopilots
  • high contrast LCD display for excellent visibility
  • 3 levels of display backlighting for night use
  • 28mm tall, 7-segment digits for visibility across the cockpit
  • readout in knots, kilometers per hour or miles per hour.
  • user resettable trip log
  • water temperature readout in degrees Celsius or Fahrenheit
  • master or repeater mode for displaying speed at multiple locations

Raymarine ST40 Speed Display Specifications:

  Supply voltage: 10 V to 16 V dc.
  Current consumption (12 V supply): 25 mA typical. 60 mA with maximum backlighting.
  Operating temperature: 0°C to +70°C.
  Interfaces: SeaTalk.
  Overall dimensions: 126 mm x 70 mm x 38 mm (5.00 inches x 2.80 inches x 1.55 inches).
  Boss diameter: 55 mm (2.20 inches).
  Speed range: 0 to 99.9 knots.
  Log range: 0 to 99999.
  Trip range: 0 to 999 nautical miles.
  Water temperature reading range: -10°C to +40°C.
  CE - conforms to 89/336/EC(EMC), EN60945.94/25/EC(RCD), EN28846 (applies to transducer only).
